Flame sensor module







Share:

A sensor module to detect flames. The spectral sensitivity of the sensor
is optimized to detect emissions from naked flames. The output signal
‘DO’ is pulled high (active high) when a flame is detected. The switching
threshold is adjustable via a preset pot. An analog output signal from
the sensor is available at pin ‘AO’.

Typical spectral sensitivity: 720-1100nm

Typical detection angle: 60°





Example Code

//Example for KY-026










//TkkrLab










int









	 Led =









	 13









	 ;









	// define LED Interface










int









	 buttonpin =









	 3









	;









	 // define the flame sensor interface










int









	 analoog =









	 A3;









	 // define the flame sensor interface











int









	 val ;









	// define numeric variables val










float









	 sensor;









	 //read analoog value











void









	 setup ()










{










  pinMode (









	Led,









	 OUTPUT)









	 ;









	// define LED as output interface










  pinMode (









	buttonpin,









	 INPUT)









	 ;









	// output interface defines the flame sensor










  pinMode (









	analoog,









	 INPUT)









	 ;









	// output interface defines the flame sensor










  Serial.begin









	(









	9600









	)









	;










}











void









	 loop ()










{










  sensor =









	 analogRead(









	analoog)









	;










  Serial.println









	(









	sensor)









	;









	  // display tempature











  val =









	 digitalRead (









	buttonpin)









	 ;









	// digital interface will be assigned a value of 3 to read val










    if









	 (









	val ==









	 HIGH)









	 // When the flame sensor detects a signal, LED flashes










  {










    digitalWrite (









	Led,









	 HIGH)









	;










  }










  else










  {










    digitalWrite (









	Led,









	 LOW)









	;










  }










  delay(









	1000









	)









	;










}
