High Sensitivity Microphone Electret Condenser Sound Sensor

High Sensitivity Microphone Electret Condenser Sound Sensor

KWD0.750KWD0.750
0%Off

High Sensitivity Microphone Electret Condenser Sound Sensor







Share:
Operating Voltage3-15V DC
Board Size3.2 cm x 1.6 cm


A microphone module featuring a high-sensitivity large-format electret
capsule. Output ‘DO’ (active high) is switched when the sound level
exceeds a preset level. A pot allows adjustment of the level. The analog
output signal is available at the ‘AO’ pin.





Microphone sound detection module

For sound detection Module has two outputs:

  1. AO, analog output, real-time output voltage signal of the microphone
  2. DO, when the sound intensity reaches a certain threshold, the output high and low signal

The threshold-sensitivity can be adjusted via potentiometer on the sensor

Connecting to the Arduino

  • Pin + to Arduino 5+
  • Pin - to Arduino -
  • Pin A0 to Arduino A0 (for analog program)
  • Pin D0 to Arduino 13 (for digital program)

Example code: Digital output

int



	 Led =



	 13



	 ;



	// define LED Interface




int



	 buttonpin =



	 3



	;



	 // define D0 Sensor Interface




int



	 val =



	 0



	;



	// define numeric variables val





void



	 setup ()




{




  pinMode (



	Led,



	 OUTPUT)



	 ;



	// define LED as output interface




  pinMode (



	buttonpin,



	 INPUT)



	 ;



	// output interface D0 is defined sensor




}





void



	 loop ()




{




  val =



	 digitalRead(



	buttonpin)



	;



	// digital interface will be assigned a value of pin 3 to read val




  if



	 (



	val ==



	 HIGH)



	 // When the sound detection module detects a signal, LED flashes




  {




    digitalWrite (



	Led,



	 HIGH)



	;




  }




  else




  {




    digitalWrite (



	Led,



	 LOW)



	;




  }




}





Example Code : analog outputs

int



	 sensorPin =



	 A0;



	 // select the input pin for the potentiometer




int



	 ledPin =



	 13



	;



	 // select the pin for the LED




int



	 sensorValue =



	 0



	;



	 // variable to store the value coming from the sensor





void



	 setup ()




{




  pinMode (



	ledPin,



	 OUTPUT)



	;




  Serial.begin



	 (



	9600



	)



	;




}





void



	 loop ()




{




  sensorValue =



	 analogRead (



	sensorPin)



	;




  digitalWrite (



	ledPin,



	 HIGH)



	;




  delay (



	sensorValue)



	;




  digitalWrite (



	ledPin,



	 LOW)



	;




  delay (



	sensorValue)



	;




  Serial.println



	 (



	sensorValue,



	 DEC)



	;




}
