CD4027 IC

Features:-

• Set-Reset capability
• Static flip-flop operation — retains state indefinitely with clock level either "high" or "low"
• Medium speed operation — 16 MHz (typ.) clock toggle rate at 10 V
• Standardized, symmetrical output characteristics
• 100% tested for quiescent current at 20 V
• Maximum input current of 1 µA at 18 V over full package-temperature range; 100 nA at 18 V and 25°C
• Noise margin (full package-temperature range) =
      1 V at V_DD = 5 V
      2 V at V_DD = 10 V
      2.5 V at V_DD = 15 V
• 5-V, 10-V, and 15-V parametric ratings
• Meets all requirements of JEDEC Tentative Standard No. 13B, "Standard Specifications for Description of ’B’ Series CMOS Devices"
• Applications:
  • Registers, counters, control circuits

Specifications:-

Related Document:-

CD4027 IC Datasheet
