18650 - 3300MAH rechargeable battery 3.6V 3300MAH lithium ion battery

18650 - 3300MAH rechargeable battery 3.6V 3300MAH lithium ion battery

KWD1.750KWD1.750
0%Off

18650 - 3300MAH rechargeable battery 3.6V 3300MAH lithium ion battery


12 products available






  • SKU: 350958
Share:
Product Description
NO.ItemSpecifications
1Nominal Voltage3.6V
2Nominal Capacity3350mAh
3Minimum Capacity

3250mAh

4Standard chargeCCCV, 0.3C(975mA), 4.2V, 50mA cut-off
5Rapid charge1625mA
6Standard Discharge0.2C (650mA)
7Max. Disharge Current

0.5C(1625mA)

1.5C(4875mA)

8Max. Pulse Discharge2.0C(6500mA)
9Discharge Cut-off Voltage2.5V
10Cell weight

49.0g max.

11Cell dimension (max.)

Height : 18.6mm

Diameter : 65.2mm

12Operating temperature
(surface temperature)

 Charge : 0 to 45°C
Discharge: -20 to 50°C

13Storage temperature
(Recovery 90% after storage)

1 year -20~25°C
3 months -20~45°C
1 month -20~50°C





Features
  1. High capacity 3350mAh to ensure longer working time.
  2. With PTC inside, can be used as an alternative cell of Panasonic NCR18650B
  3. Small internal resistance
  4. High energy density, low self-discharge
  5. Cost-effective cell, good option for OEM battery packs assembly.
  6. UN38.3, IEC62133, CE, ROHS approved
  7. Applicable to a wide range of electronic devices, such as flashlight, torch light, laptop, bike light, UPS, ESS, POS machine, power bank, shaver, monitor, medical equipment and so on.
