bdx53c transistor

bdx53c transistor

KWD0.500KWD0.500
0%Off

bdx53c transistor







Share:

BDX53C is a three layer NPN device within the working range, the collector current IC is a function of the base current IB, a change in the base current giving a corresponding amplified change in the collector current for a given collector emitter voltage VCE.



Features:-

• Low saturation voltage

• Simple drive requirements

• High safe operating area

• For low distortion complementary designs

• Easy to carry and handle



Detailed Specifications:-

Transistor Polarity NPN
Collector−Emitter Voltage (VCEO) 100V
Collector−Base Voltage (VCBO) 100V
Continuous Collector Current (Ic) 8A
Continuous Base Current (Ib) 0.2mA
Operating Temperature Range -65 - 150°C
Power Dissipation (Pd) 60W
DC Current Gain (hFE) 750
Emitter-Base Voltage (VEBO)  5V



Related Documents:-

pdf.jpgBDX53C Transistor Datasheet
